Single Tube Fiber Optic Tools , High Precision Cutting Cleaver 0.5° Cleaver Angle MT 8521

Name: Single Tube Fiber Optic Tools High Precision Cutting Cleaver 05 Cleaver Angle MT 8521
Brand: Melontel
Price: 1 USD

Quality Single Tube Fiber Optic Tools , High Precision Cutting Cleaver 0.5° Cleaver Angle MT 8521 wholesale

Brand Name : Melontel

Model Number : MT-8521

Certification : ISO9001:2008

Place of Origin : Ningbo,China

MOQ : 10 Piece/Pieces (Min. Order)

Price : US $1-10 / Pieces

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability : 1000 Piece/Pieces per Day

Delivery Time : 5 days

Packaging Details : 1 PCS /BOX

Product name : Fiber optic cleaver

Application : Fiber optic cutting

Color : Gray and blue

Fiber Type : Single Tube fiber and ribbon fiber

Cleaver length : 5-30mm

Cleaver angle : 0.5°

Packing : 1 pcs/box

Dimension : 63*76*63mm

Contact Now

MT 8521 Fiber Optic Tools , High Precision Cutting Cleaver 0.5° Cleaver Angle

Bare fiber diameter	0.25mm~0.9mm
Outercoat diameter	125µm
Fiber type	Single tube fiber and Ribbon fiber(exchangeable)
Cleaved length	9~16mm(φ0.25) 10~16(φ0.9)
Cleaved angle	≤0.5°
blade life	48,000cleaves
Mode	Semiautomatic
Dimension	63mm(W)76mm(D)63mm(H)
Weight	565g

The Fibretool FC-6S high precision cleaver is designed for field use alongside the Sumitomo splicing units. By using a rotating blade for multiple scoring positions enables a blade life of 48,000 cleaves with a cleave angle better than 0.5 degrees. The unit is constructed to be robust and field serviceable and has options such as tripod mount to enable secure platform mounting. The FC-6S is the latest cleaver . Integral to the unit is a cleave length scale which helps facilitate exact lengths during cleaving.

Features

· - Used for Single Fiber Cleaving with Fiber Scrap Collection

· - Utilizes an Automatic Anvil Drop for Fewer Required Steps and Better Cleave Consistency

· - Prevents Double Scoring of the Fibers

· - Has Superior Blade Height and Rotational Adjustment

· - Precision Blade features 24 blade positions with 2,000 cleavers per position

· - Can Be Operated With Minimal Steps
